Description
Series for maximum lift or parallel for maximum airflow, with the AirFlow+ vacuum system, it’s your call!
The AirFlow+ vacuum system allows you to quickly change your vacuum motors from a series configuration to a parallel configuration in under a minute with no mechanical skill needed.
Whether you’re extracting flood water and need maximum lift or cleaning tile and need maximum airflow, the Nautilus has you covered.
Low monthly payments are available. Contact your distributor for more information.
The Nautilus portable extractor achieved Platinum Certification from the Carpet and Rug Institute (CRI). The Platinum Certification is the highest designation available from CRI and highlights the superior cleaning and water extraction achieved with a Nautilus portable extractor.
Specifications:
Two 3-stage vacuum motors
1,200 PSI solution pump
12″ rear wheels and 5″ casters
Roto-molded polyethylene body
12 gal. solution and waste tank
Dimensions: 42″ H x 34″ L x 23″ W
160 lbs.
Standard Items:
Auto Fill
Auto Pump Out (3/4″ x 50′ pump out hose included)
Two 25′ extension cords
AH224 2″ Flash Cuff starter
AH201 2″-1.5″ Flash Cuff reducer
Get over $400 worth of items for only $200 more when you buy a machine with the hose package!
Hose Package Includes:
Hydro-Filter
25′ of vacuum hose
25′ of high pressure solution hose w/QCs
4 Vinyl cuffs
3/4″ x 50′ pump-out hose
3/8″ x 50′ auto-fill hose
*1200 PSI hose packages do not include a carpet wand
Vacuum Motor Specifications for Series and Parallel Configurations
Item #
CFM Ratings
Lift Ratings (inH20)
Max Air Watts
MX200M
Series: 97CFMParallel: 194CFM
Series: 130.9Parallel: 81.8
250
MX200HM
Series: 97CFMParallel: 194CFM
Series: 130.9Parallel: 81.8
250
MX3-200M
Series: 99CFMParallel: 198CFM
Series: 187.8Parallel: 117.4
368
MX3-200HM
Series: 99CFMParallel: 198CFM
Series: 187.8Parallel: 117.4
368
MX500M
Series: 97CFMParallel: 194CFM
Series: 130.9Parallel: 81.8
250
MX500HM
Series: 97CFMParallel: 194CFM
Series: 130.9Parallel: 81.8
250
MX3-500M
Series: 99CFMParallel: 198CFM
Series: 187.8Parallel: 117.4
368
MX3-500HM
Series: 99CFMParallel: 198CFM
Series: 187.8Parallel: 117.4
368
MX1200M
Series: 97CFMParallel: 194CFM
Series: 130.9Parallel: 81.8
250
MX3-1200M
Series: 99CFMParallel: 198CFM
Series: 187.8Parallel: 117.4
368
MXE-200M
Series: 142CFMParallel: 284CFM
Series: 235Parallel: 147
673
MXE-500M
Series: 142CFMParallel: 284CFM
Series: 235Parallel: 147
673
CFM and Lift ratings are for two vacuum motors, while Max Air Watts are for a single vacuum motor only.
